Recloser NX2007868
Manages all the functions needed for a correct functionning of Smartclosers installed on the MV networks.
| Code | NX2007868 |
| GTIN | 03700540436525 |
| Name | Recloser Control box for Smartcloser -50°C with protection relay |
| Dimensions | |
|---|---|
| Weight | 53 kg |
| Height | 700 mm |
| Width | 400 mm |
| Length | 500 mm |
| Standards | |
| Standards | IEC 60060-1:2010 |
| Electrical values | |
| Rated Voltage (Ur) | 0.23 kV |
| Features | |
| Degree of protection | IP55 |
| Protection relay | ANSI functions : 50P, 50N, 50SG, 46, 51P, 51N, 51SG, 67P, 67N, 67SG, 27, 59, 47, 81L, 81H, 46BC, 50BF, 49, Cold load pick up, Inrush restrain, High current lockout, Hot line tag. Each controller can be provided with INGETEAM or ARCTEQ relays |
| Communication protocols | IEC60870-5-101 - IEC60870-5-104 - DNP3 serial - DNP3 IP - Modbus IP - Modbus RTU - IEC61850 - GOOSE |
| Pallet package | |
|---|---|
| Size | 1 pce |
| Depth | 1200 mm |
| Width | 800 mm |
| Weight | 73.000 kg |
